HIVseqDB

Webserver for storage [and analysis] of NGS-based HIVDR testing data

View the Project on GitHub

Twitter Follow

Introduction

Portable resource for management and analysis of NGS-based HIV Drug Resistance Data. Secure management of uploaded NGS data, matched with sample data. HIVseqDB provides a searchable database protected through user authentication. NGS-based HIVDR data is asynchronously analysed using state of the art tools. Results are given off in user friendly pages and exportable in various formats. HIVseqDB can be deployed on different computing environments. It is distributed with guidelines for setting it up for on-prem and cloud-based compute solutions. A quick demonstration of HIVseqDB in production is available at https://hivseqdb.org/.

Working with the development version

Clone this repository.

git clone https://github.com/AlfredUg/HIVseqDB.git

Navigate to the cloned repository

cd HIVseqDB

Switch over to the development branch

git checkout dev

Create a virtual environment and activate it.

python3 -m venv venv
source venv/bin/activate

Install dependancies

pip install -r requirements.txt

In addition, have a working version of sierralocal and quasitools.

pip install sierralocal
conda install -c bioconda quasitools

Setting up the SECRET_KEY. To set this manually, open the settings file (located at $(PWD)/hivseqdb/settings.py, and add a value for the SECRET_KEY or export it to the system PATH as indicated below.

export SECRET_KEY='some-hash-string'

Make migrations and execute them

python manage.py makemigrations
python manage.py migrate

Run the server

python manage.py runserver

Start redis on a different shell tab/window

redis-server

Start Celery on a different shell tab/window

python -m celery -A hivseqdb worker

Note: Quasitools and Sierralocal should ba accessible in the environment in which Celery runs.

Working with the Docker version

HIVseqDB requires docker to pull and run the containerised services, if you have docker available, proceed to next steps. Otherwise, install it from https://docs.docker.com/engine/install/.

Download HIVseqDB from GitHub and checkout to the docker branch.

git clone https://github.com/AlfredUg/HIVseqDB.git
cd HIVseqDB
git checkout docker

Build HIVseqDB using the docker-compose command.

sudo docker-compose build

Secondly, run all the containers.

sudo docker-compose up

If everything looks good, deploy HIVseqDB.

sudo docker-compose up --build -d

The server will be running at: http://127.0.0.1. We are almost there. We need to set up the database and create a super user, which we can do by interactively running the server container of HIVseqDB.

sudo docker exec -it hivseqdb-docker_server_1 bash

Create a super user for the admin role.

python manage.py createsuperuser

Usage

Below is a quick video of the HOW-TOs of HIVseqDB.

NOTE: The NGS data used in this demonstration is publically available at the NCBI Sequence Read Archive (SRA) and the European Nucleotide Archive (ENA), Bioproject accession PRJNA340290. Corresponding sample data was obtained from the associated publication. Many thanks to Avila-Ríos, Santiago, et al. “HIV drug resistance in antiretroviral treatment-naïve individuals in the largest public hospital in Nicaragua, 2011-2015.” PLoS One 11.10 (2016): e0164156.

Alt text for your video

Test data

To demonstrate the usage of HIVseqDB, download real HIV-1 NGS data from the European Nucleotide Archive (ENA), Bioproject accession PRJNA340290.

wget ftp://ftp.sra.ebi.ac.uk/vol1/fastq/SRR408/002/SRR4089862/SRR4089862_1.fastq.gz
wget ftp://ftp.sra.ebi.ac.uk/vol1/fastq/SRR408/002/SRR4089862/SRR4089862_2.fastq.gz
wget ftp://ftp.sra.ebi.ac.uk/vol1/fastq/SRR408/004/SRR4089864/SRR4089864_1.fastq.gz
wget ftp://ftp.sra.ebi.ac.uk/vol1/fastq/SRR408/004/SRR4089864/SRR4089864_2.fastq.gz
gunzip *.gz

Get corresponding sample data from the associated publication. Again, many thanks to Avila-Ríos, Santiago, et al. We use the formatted version of the data, but the original file is available here.

wget https://raw.githubusercontent.com/AlfredUg/HIVseqDB/main/data/Santiago2016_short.csv

Follow the instructions as demonstrated in the video to upload, analyse and browse.

Dependancies

Below is the list of key tools that are used by HIVseqDB. See requirements.txt for other dependancies.

Web, server, data management

HIVseqDB UI/UX

Analysis of HIV drug resistance

Troubleshooting

Kindly report any issues at https://github.com/AlfredUg/HIVseqDB/issues.

License

HIVseqDB is licensed under GNU GPL v3.

Citation

This work is currently under peer review. A formal citation will be availed in due course.
